Eaton APSINT3636VR - APSINT3636VR

Eaton APSINT3636VR - APSINT3636VR

Write a Review

$2,572.76

Brand: Eaton
SKU:: APSINT3636VR
UPC:
Condition:: New

Current Stock:

Quantity:

Adding to cart… The item has been added

Description
0 Reviews

Tech Specs

Specifications

Manufacturer	Tripp Lite by Eaton
Manufacturer Part Number	APSINT3636VR
Manufacturer Website Address	http://www.tripplite.com
Brand Name	Tripp Lite
Product Line	PowerVerter
Product Series	APS
Product Model	APSINT3636VR
Product Name	APS PowerVerter INT APSINT3636VR Power Inverter With Charger
Marketing Information	The APSINT3636VR 3600W APS INT Series 36V DC 230V AC Inverter/Charger is a reliable power source for a wide variety of equipment ranging from power tools, pumps and portable lighting to laptop computers and sensitive monitoring equipment. With no fumes, fuel or excess noise, it's an excellent alternative to generator power.The DC-to-AC inverter features an automatic line-to-battery transfer switch and integrated charging system that allow it to work as a vehicle inverter, standalone AC power source or extended-run UPS. It delivers 3600W of continuous power, 5400W up to one hour or 7200W of peak power up to 10 seconds during equipment startup or cycling. An automatic overload detector, cooling fan and resettable AC circuit breakers protect the unit from damage.Designed for easy installation in RVs, commercial and fleet vehicles, emergency vehicles and construction equipment, the APSINT3636VR converts stored power from any 36V battery or automotive DC source to safe, stable, computer-grade AC power for unlimited runtime. When hardwired to an external 230V AC source, the unit keeps the user-supplied battery charged via a three-stage 7.5/30A selectable charging system while simultaneously delivering AC power to connected equipment.When used as a UPS, the APSINT3636VR's automatic voltage regulation feature protects your equipment against blackouts, brownouts, surges and line noise. Tripp Lite's APSRM4 module with "traffic light" LEDs is included to provide complete remote monitoring and control of the unit.
Product Type	Power Inverter

Technical Information

Plug/Connector Type	Hardwired
Receptacles	Hardwired

Power Description

Input Voltage	36 V DC 230 V AC
Input Voltage Range	30 V DC - 45 V DC
Output Voltage	230 V AC 36 V DC
Maximum Frequency	50 Hz
Peak Power Load	7200 W
Continuous Power Load	3600 W
Waveform Type	Pulse-width Modulated Sine Wave

Physical Characteristics

Product Color	Black
Height	7.3"
Width	8.5"
Depth	16.3"
Weight (Approximate)	61 lb

Miscellaneous

Additional Information	DC Input: Requires 36 VDC input source capable of delivering 114 A AC Input: 230 VAC AC Output: 230 VAC nominal DC Charger Output: 36 VDC nominal DC Input connection type: Set of DC bolt-down terminals AC Input connection type: Hardwire via built in junction box with cover plate Cooling method: Fan Transfer time from line power to battery mode: 4 to 6 milliseconds Low voltage transfer to battery power: User configurable to 144V, 163V, 182V & 201V High voltage transfer to battery power: User configurable to 259 to 278V Frequency control for operating stability Resettable circuit breaker protects APS against system overload RJ45 port allows connection of APS remote switch (part# APSRM) Switch allows user to select between off, auto-invert and charge-only settings Advanced 30 amp, 3-stage battery charger and selector switch for gel or wet cell batteries Allows unlimited runtime capability by allowing the use any number of user-supplied batteries Battery runtime is dependent upon the size and number of user-supplied batteries in 36-volt configuration Overload protection: Includes 12 A input breaker dedicated to the charging system and 20 A output breaker for AC output loads
Package Contents	APS PowerVerter INT APSINT3636VR Power Inverter With Charger Instruction manual with Warranty Information Wired Remote Switch with full LED status indicators (model APSRM4)
Compatibility	Compatible with marine, automotive, telecom, computer, emergency and a variety of other applications.
Country of Origin	China

Warranty

Limited Warranty

1 Year
