Eaton B155-002-VGA - MDP TO VGA CONV
$52.82
- Brand
- Eaton
- SKU:
- B155-002-VGA
- Availability:
- Within 2 Days Shipping
The B155-002-VGA 2-Port Mini DisplayPort to VGA Splitter converts and splits a Mini DisplayPort video signal for display on two VGA-enabled monitors, projectors or televisions at the same time. Ideal for offices, conference rooms, retail settings, trade shows and classrooms, this compact splitter features a built-in Mini DisplayPort cable that connects to the source. It lets you use your existing VGA displays instead of buying new Mini DisplayPort monitors or docking stations.
The B155-002-VGA supports video resolutions up to 1080p @ 60 Hz (1920 x 1080), as well as HDCP, EDID and DDC. Orange LEDs next to each output port indicate whether the splitter is powered on and transmitting a signal to the connected displays. The splitter works with all operating systems and is small enough to carry in your backpack or computer bag. Plug-and-play convenience means no software or drivers are needed. An included USB Micro-B cable connects between the source and the splitter to provide power, so no external power supply is required.
Converts and Splits Mini DisplayPort Signal to 2 VGA Displays Simultaneously
- Ideal for offices, conference rooms, trade shows and classrooms
- Built-in Mini DisplayPort cable connects to source
- Included USB Micro-B cable supplies power to splitter
- Save money on new Mini DisplayPort displays or docking stations
Top-Shelf Performance
- Supports video resolutions up to 1080p @ 60 Hz (1920 x 1080)
- Complies with HDCP, EDID and DDC
- LEDs indicate whether splitter is powered on and transmitting signal to connected displays
Easy to Use Almost Anywhere
- Works with all operating systems
- Plug and play?o software, drivers or external power supply required
- Compact unit fits easily in backpack or computer bag
- B155-002-VGA 2-Port Mini DisplayPort to VGA Splitter
- USB Micro-B cable, 3 ft.
- Owner? manual
OVERVIEW
UPC Code | 037332191489 |
Product Type | Splitter |
Technology | DisplayPort; VGA/SVGA |
Host Connector | MINI DISPLAYPORT (FEMALE) |
VIDEO
Max Supported Video Resolution | 1920 x 1080 (1080p) @ 60Hz |
Max Supported Color Depth | 24-bit True Color |
3D Video Supported | Yes |
AUDIO
Audio Specification | 2.0-channel surround sound audio |
POWER
Power Consumption (Watts) | 4.1 |
USER INTERFACE, ALERTS & CONTROLS
LED Indicators | (x2) Orange (Monitor Signal) |
PHYSICAL
Color | Black |
Material of Construction | Polycarbonate |
Cable Length (m) | 0.00 |
Rackmountable | No |
Shipping Dimensions (hwd / cm) | 20.07 x 14.22 x 4.32 |
Shipping Weight (kg) | 0.27 |
Unit Dimensions (hwd / cm) | 7.6 x 6.15 x 2.55 |
Unit Dimensions (hwd / mm) | 61.5 x 76 x 25.5 |
Unit Packaging Type | Box |
Unit Weight (kg) | 0.07 |
ENVIRONMENTAL
Operating Temperature Range | 14? to 167?F (10? to 75?C) |
Storage Temperature Range | -4? to 176?F (-20? to 80?C) |
Relative Humidity | 0% to 85%, Non-Condensing |
BTUs | 14 BTU/Hr |
COMMUNICATIONS
EDID Compatible | Yes |
CONNECTIONS
Number of Ports | 2 |
Side A - Connector 1 | MINI DISPLAYPORT (MALE) |
Side A - Connector 2 | MICRO-USB B (FEMALE) |
Side B - Connector 1 | (2) HD15 (FEMALE) |
Connector Plating | Nickel |
Contact Plating | Gold |
Input x Output | 1 x 2 |
FEATURES & SPECIFICATIONS
MST Support | No |
Displayport Specification | 1.2 |
HDCP Specification | 1.3 |
Driver Required | No |
STANDARDS & COMPLIANCE
Product Compliance | RoHS; CE (Europe); REACH; FCC (USA); Trade Agreements Act (TAA) |
WARRANTY & SUPPORT
Product Warranty Period (Worldwide) | 3-year limited warranty |
