Eaton BP36V27-2US - BP36V27-2US
Write a Review
Write a Review
![Eaton BP36V27-2US - BP36V27-2US Eaton BP36V27-2US - BP36V27-2US](https://cdn11.bigcommerce.com/s-x1sv5q2jxe/images/stencil/500x659/products/3289/5032/bp36v272us-front-l__43864.1712148832.jpg?c=1)
Eaton
Eaton BP36V27-2US - BP36V27-2US
MSRP:
Now:
$1,213.06
Was:
(You save
)
- Brand
- Eaton
- SKU:
- BP36V27-2US
- UPC:
- Availability:
- Within 2 Days Shipping
External Battery Pack Gives Your Compatible UPS System Extended Runtime
The BP36V2
External Battery Pack Gives Your Compatible UPS System Extended Runtime
The BP36V27-2US is compatible only with select 36V DC UPS systems that specify the use of this battery pack. Not only does it provide extended runtime, but it can also be daisy-chained using its rear connector to additional external battery packs for even longer extended-run operation. Heavy-gauge cabling with high-current two-point DC connector is included for simple installation. Optional-use rear-panel battery detection jacks automatically configure host UPS systems supporting this feature for one or more external battery packs.
Versatile Installation Options Allow You to Place the Battery Where Most Needed
The steel housing supports mounting in 2U of space in EIA-standard 19-inch racks using the included 4-post rack-mounting brackets. The BP36V27-2US is also compatible with 2-9USTAND for upright tower configuration, 2POSTRMKITWM for 2-post racks or wall installation and UPDHDEARKIT for 2-point front-rail rack installation without rear supports (all accessories sold separately).
2-Year Warranty
The BP36V27-2US is backed by a 2-year warranty, ensuring reliability and performance.
- BP36V27-2US 36V External Battery Pack w/attached DC cabling
- Rack-mounting hardware
- Owners manual
OVERVIEW
UPC Code | 037332181770 |
INPUT
Input Phase | Single-Phase |
BATTERY
DC System Voltage (VDC) | 36 |
UPS Connection | Attached 18in. / 457mm 6AWG cable with 50A gray 2-point DC connector |
Typical Battery Lifespan | 3-6 years typical (North America) |
PHYSICAL
Material of Construction | Steel |
Rack Height | 2U |
External Battery Pack Form Factor | Rack/Tower |
Included Mounting Accessory Description | Included 4POSTRAILKIT mounting bracket enables installation in 4 post racks from 20.5 to 36 inches (521 to 914mm) |
Installation Form Factors Supported with Included Accessories | 4 post 19 inch rackmount |
Installation Form Factors Supported with Optional Accessories | 2 post rackmount ( 2POSTRMKITWM ); 2-4 post front rail rackmount ( UPSHDEARKIT ); 4 post rackmount short-depth ( 4POSTRAILKITWM ); Tower ( 2-9USTAND ); Wallmount ( 2POSTRMKITWM ) |
Minimum Required Rack Depth (cm) | 66.04 |
Optional Mounting Accessory Notes | Optional 2-9USTAND enables upright tower UPS placement; 2POSTRMKITWM enables wall-mount and 2-post rackmount installation; 4POSTRAILKITWM enables installation in 4-post short-depth racks from 14.5 to 23.5 inches (368 to 597mm); UPSHDEARKIT enables installation in 2 or 4-post racks using front vertical rails only, without rear support |
Shipping Dimensions (hwd / cm) | 24.13 x 67.31 x 72.39 |
Shipping Weight (kg) | 47.63 |
Unit Dimensions (hwd / cm) | 8.71 x 44 x 57.4 |
Unit Weight (kg) | 31.26 |
STANDARDS & COMPLIANCE
Product Compliance | RoHS; CE (Europe); UKCA |
WARRANTY & SUPPORT
Product Warranty Period (International) | 1-year limited warranty |
