Eaton SMART2200RM2UL - SMART2200RM2UL

Eaton SMART2200RM2UL - SMART2200RM2UL

Write a Review
$3,492.00
Brand
SKU:
SMART2200RM2UL
Condition:
New
Adding to cart… The item has been added
Add to Wish List

Eaton SMART2200RM2UL - SMART2200RM2UL

Trionics Distributor of Tripp Lite By Eaton,

MPN: SMART2200RM2UL

Tech Specs
Specifications

Manufacturer Part Number

SMART2200RM2UL

Brand Name

Tripp Lite

Product Line

SmartPro

Product Model

SMART2200RM2UL

Product Name

SmartPro SMART2200RM2UL 2200VA UPS

Marketing Information

  • Protects Mission-Critical Rack-Mounted Equipment
    • Provides fully regulated sine wave AC output for servers, network storage devices, telecom hardware and other applications where long battery lifespan is critical
    • Audible alarm signals loss of utility power, overload and low battery
    • 4 NEMA 5-15R & 4 NEMA 5-15/20R outlets
    • 10-ft. (3.05 m) power cord with 120V NEMA 5-20P input
    • 570-joule surge suppression rating
    • 0.9 power factor rating
    • 97% line-mode efficiency rating saves money in energy costs
    Superior LiFePO4 Battery Backup Compared to Equivalent Lead Acid Battery
    • More than 2x the service life
    • Up to 3x more charge/discharge cycles
    • Recharges to 100% capacity in less than 2 hr.
    • Weighs 60% less, reducing overall UPS weight
    • Supports half load up to 11.7 min. and full load up to 5.1 min.
    2 Load Banks with Switchable Outlets
    • Can control 2 outlets remotely to reboot equipment or shed nonessential loads
    Automatic Voltage Regulation (AVR)
    • Maintains 120V nominal output over input range of 83V-145V without using battery power
    EMI/RFI Line Noise Filtering
    • Removes electromagnetic and radio frequency interference that can disrupt or damage equipment's performance
    Interactive LCD Screen
    • Front-panel LCD with detailed UPS and site power status and operating data
    • Rotates for easy viewing in rack-mount or tower configurations
    Optional Network Management Cards
    • Compatible with Tripp Lite UPS management cards WEBCARDLX, SNMPWEBCARD and RELAYIOCARD
    Communications Ports
    • USB and DB9 ports enable data-saving unattended shutdown when used with Tripp Lite PowerAlert software (available via free download at <li">www.tripplite.com/poweralert
    • <li">EPO port supports emergency shutdown in large facilities
    Versatile Installation Options
    • Hardware included for 4-post mounting in 2U of EIA-standard 19 in. rack
    • Mounts on wall or 2-post rack with optional 2POSTRMKITWM accessory
    • Mounts in upright tower position with optional 2-9USTAND accessory
    Backed by Tripp Lite's Ultimate Lifetime Insurance
    • 250,000 Ultimate Lifetime Insurance covers any connected components

Product Type

Line-interactive UPS
Technical Information

Plug/Connector Type

NEMA 5-20P

Receptacle Type

  • NEMA 5-15/20R
  • NEMA 5-20

Receptacle Detail

  • 4 x NEMA 5-15/20R
  • 4 x NEMA 5-20

Protection Type

  • Over Voltage
  • Under Voltage

Emergency Power OFF

Yes

Transfer Time

5 ms

EMI/RFI Noise Filter

Yes

Phase

Single Phase

Application/Usage

  • Server
  • Network Storage Device
Power Description

Load Capacity

2200 VA/1920 W

Input Voltage

120 V AC

Output Voltage

  • 110 V AC
  • 115 V AC
  • 120 V AC

Input Current

16 A

Waveform Type

Pure Sine Wave

Surge Energy Rating

570 J

Circuit Breaker

Yes
Management

Alarm

  • UPS StartUp
  • Power Failure
  • Low Battery
  • Overload
  • UPS Fault
  • Remote Shutdown
Interfaces/Ports

Serial Port

Yes

USB

Yes
Battery Information

Backup/Run Time (Full Load)

5.10 Minute

Backup/Run Time (Half Load)

11.70 Minute

Typical Battery Recharge Time

1.40 Hour

Hot Swappable

Yes
Environmental Conditions

Maximum Operating Temperature

122?F (50?C)

Sound Emission (A-Weighted)

45 dB(A)

Thermal Dissipation

393.59 W
Physical Characteristics

Height

3.4"

Width

19.4"

Depth

17.3"

Rack Height

2U

Form Factor

Rack-mountable

Weight (Approximate)

41.78 lb
Miscellaneous

Package Contents

  • SmartPro SMART2200RM2UL 2200VA UPS
  • USB cable
  • DB9 cable
  • EPO cable
  • Rack-mounting hardware
  • Owner's manual

Certifications & Standards

  • UL1778 (USA)
  • Tested to CSA (Canada)
  • Tested to NOM (Mexico)
  • Meets FCC Part 15 Category A (EMI)

Environmentally Friendly

Yes

Environmental Certification

RoHS

Country of Origin

United States
Warranty

Limited Warranty

5 Year
