Eaton SPD160240H3J - SPD series160kA240V HLSTD+CntrMCC
Write a Review
Write a Review
Eaton
Eaton SPD160240H3J - SPD series160kA240V HLSTD+CntrMCC
$11,839.00
- Brand
- Eaton
- SKU:
- SPD160240H3J
- Availability:
- In Stock
Surge Protection Device, SPD series, For motor control centers, 160 kAIC, 240V high-leg delta (4W+G) on B phase, Standard feature package and surge counter, Internal integrated mount, 150 L-N, 150 L-G, 150 N-G, 300 L-L operating voltage
General specifications
Product Name
Eaton SPD series surge protection device
Catalog Number
SPD160240H3J
UPC
786685325279
Product Length/Depth
9.5 in
Product Height
3.45 in
Product Width
5.4 in
Product Weight
3.5 lb
Warranty
15 year
Certifications
UL 1449
UL Listed
UL Listed
Product specifications
Special features
Meets or exceeds the requirements specified in IBC ?2006, CBC2007, and UBC?Zone 4. Audible alarm with silence button. Form C relay contact. EMI/RFI filtering, providing up to 50 dB of noise attenuation from 10 kHz to 100 MHz. Surge counter with rest button
Interrupt rating
200 kAIC
Surge current
160 kA per phase
Mounting Method
Internal integrated
Nominal Discharge Current
20 kA
Short-circuit rating
200 kA
Accessories
Standard feature package and surge counter
Type
SPD
Operating voltage
150 L-N, 150 L-G, 150 N-G, 300 L-L
Used with
Motor control centers
Frequency rating
50/60 Hz
Operating temperature
-40 to 50 ?C
Voltage rating
240 delta (4W+G)
