Eaton SPD250600D3F - SPD series250kA600V 3PHSTD+CntrTop
Write a Review
Write a Review
Eaton
Eaton SPD250600D3F - SPD series250kA600V 3PHSTD+CntrTop
$20,959.00
- Brand
- Eaton
- SKU:
- SPD250600D3F
- Condition:
- New
Eaton Surge Protective Device, Standard with COUNTER PKG., TOP TERMINALSSPD, 250KA, STD W/COUNTER PKG., TOP TERMINALS (TT)
General specifications
Product Name
Eaton SPD series surge protection device
Catalog Number
SPD250600D3F
UPC
786679198599
Product Length/Depth
12 in
Product Height
6 in
Product Width
12 in
Product Weight
13.5 lb
Certifications
UL 1449
UL 1283
UL Listed
UL 1283
UL Listed
Product specifications
Special features
Meets or exceeds the requirements specified in IBC ?2006, CBC2007, and UBC?Zone 4. Audible alarm with silence button. Form C relay contact. EMI/RFI filtering, providing up to 50 dB of noise attenuation from 10 kHz to 100 MHz. Surge counter with rest button
Interrupt rating
200 kAIC
Surge current
250 kA per phase
Mounting Method
Internal integrated
Nominal Discharge Current
20 kA
Short-circuit rating
200 kA
Accessories
Standard feature package and surge counter
Type
Surge protection device
Operating voltage
840 L-G, 840 L-L
Used with
panelboards (PRL-C)
Frequency rating
50/60 Hz
Operating temperature
-40 to 50 ?C
Voltage rating
600 delta (4W+G)
