Eaton U422-003 - 3FT USB 3.2 C B CBL,
$22.07
- Brand
- Eaton
- SKU:
- U422-003
- Availability:
- Within 2 Days Shipping
The U422-003 USB 3.2 Gen 1 Cable connects the USB Type-C (USB-C) port on your smartphone, tablet, Ultrabook or computer to a device with a USB Type-B port, such as a printer, a scanner or an external hard drive. The 3-ft. (0.91 m) cable supports data transfer speeds up to 5 Gbps. Unlike traditional USB cables that can be attached only one way, the reversible USB Type-C male connector plugs into a USB port in either direction for fast, fumble-free connection every time. Superior foil shielding provides reliable, error-free data communication. Nickel-plated molded end connectors and gold-plated copper contacts ensure superior conductivity and long life. Slim form supports evolving design trends toward smaller devices.
Supports USB 3.2 Gen 1
- Data transfer speeds up to 5 Gbps?0 times faster than USB 2.0
- Uses USB Type-B male connector
USB Type-C (USB-C) Male Connector
- Fumble-free reversible plug ensures fast, easy connection every time
- Powerful enough for smartphones, tablets, computers and other larger platforms
Premium Construction
- Gold-plated copper contacts and nickel-plated molded ends provide a lifetime of heavy use and superior conductivity
- Superior foil shielding offers reliable, error-free data communication
- Slim, sleek design tailored for emerging design trends toward smaller devices
- U422-003 USB 3.2 Gen 1 (5 Gbps) Cable, USB Type-C (USB-C) to USB Type-B M/M, 3-ft. (0.91 m)
OVERVIEW
UPC Code | 037332189264 |
Technology | Thunderbolt; USB 3.x |
Cable Type | Passive |
PHYSICAL
Material of Construction | PVC |
Cable Jacket Color | Black |
Cable Jacket Rating | VW-1 |
Cable Outer Diameter (OD) | 4.5MM |
Cable Length (m) | 0.91 |
Shipping Dimensions (hwd / cm) | 22.86 x 17.78 x 1.27 |
Shipping Weight (kg) | 0.06 |
ENVIRONMENTAL
Operating Temperature Range | 14? to 140?F (-10? to 60?C) |
Storage Temperature Range | -4? to 185?F (-20? to 85?C) |
Relative Humidity | 10% to 85% RH, Non-Condensing |
CONNECTIONS
Side A - Connector 1 | USB C (MALE) |
Side B - Connector 1 | USB B (MALE) |
Connector Plating | Nickel |
Contact Plating | Gold |
Connector Style | Straight |
FEATURES & SPECIFICATIONS
USB Specification | USB 3.2 Gen 1 (up to 5 Gbps) |
STANDARDS & COMPLIANCE
Product Compliance | RoHS; CE (Europe); REACH; FCC (USA) |
WARRANTY & SUPPORT
Product Warranty Period (Worldwide) | Lifetime limited warranty |
