Icom f60 IC-F60 UHF Transceiver

Contents of the package

Features

UHF TRANSCEIVERS MDC 1200 compatible

Specifications

     GENERAL
Frequency range :
IC-F50 136–174MHz
IC-F60 400–470MHz
450–512MHz (U.S.A.)
450–520MHz (General)
• Number of Channels : Max. 128 channels/ 8 banks
• Channel spacing : 12.5/25kHz, 15/30kHz
• Antenna impedance : 50O (SMA Type)
• Frequency error : ±2.5ppm
• PLL channel step :
IC-F50 2.5/3.125kHz
IC-F60 5/6.25kHz
• Power supply requirement : 7.2V DC
• Current drain (approx) :
Transmit IC-F50 1.5A/0.7A (5W/1W)
IC-F60 1.5A/0.8A (4W/1W)
Receive AF max. 300mA
Stand-by 85mA
• Operating temperature range : –30°C to +60°C; –22°F to +140°F
• Dimensions (W — H — D) : 56 — 97 — 36.4 mm ;
(projections not included) 27/32 — 313/16 — 17/16 in.

   TRANSMITTER

• Output power : IC-F50 5.0W IC-F60 4.0W
• Modulation system : Variable reactance frequency modulation
• Max. frequency deviation : ±5kHz (wide)
±2.5kHz (narrow)
• Modulation limiting : 60–100% of Max. deviation
• Audio harmonic distortion : 3% typ. (AF 1kHz, 40% deviation)
• Spurious emissions : 70dB Min.
• Adjacent channel power : 70dB Min. (wide)
60dB Min. (narrow)
• FM Hum and Noise : 46dB typ. (wide)
40dB typ. (narrow)
• External MIC impedance : 9-pin multi connector/2.2kO

      RECEIVER

•Sensitivity : 0.25µV typ. (at 12dB SINAD)
• Squelch sensitivity : 0.25µV typ. (at threshold)
• Adjacent channel selectivity : 75dB typ. (wide)
65dB typ. (narrow)
• Spurious response : 70dB
• Intermodulation : 74dB typ.
• Hum and noise : 45dB typ. (wide)
40dB typ. (narrow)
• Audio output power : 0.5W typ. at 5% distortion with an 8O load
• External SP connector : 9-pin multi connector/8O

Measurements made in accordance with EIA-152C/204D, TIA-603.
All stated specifications are subject to change without notice or obligation.


Item number: f60
UPC: -
Package weight: 1.2 lb

---
